Cold Work Die SteelSpecial cold work die steel: Cr8Mo2VSi、HND2、HND1Universal cold work die steel: FT32、FT33、Cr12Mo1V1、Cr12MoV、Cr12、1.2379、D2、SKD11……Economical cold work die steel: Cr8Hot Work Die SteelDie-casting die steels: D·Casking、1.2888、1.2344、1.2343Hot extrusion die steelDT413hot forged die steel: NIKKAD40、1.2714Universal cold work die steel: FT413、4Cr5MoSiV1、3Cr2W8V、H13、1.2344、1.2343、SKD61……Plastic die steelDT336VAR、FS2010、FS136、FS139DTP90、10Ni3MnCuAlNIKKA30、NIKKA20、NIKKA10FT61、FT62、FT64、718、1.2738、P20……S55CLN171.20837Mn15Cr2Al3V2Wmo
TYPE | CLASS | Size / mm |
Cold working die steel | Forging | ≤Φ700 |
rolled metal | ≤Φ90 (10-90)×(60-305) (1-10)×(600-1000) | |
Hot-work die steel | Forging | ≤Φ800 |
rolled metal | ≤Φ150 | |
Plastic die steel | Forging | ≤Φ500 T: ≤810, W: ≤1300 |
rolled metal | ≤Φ150 | |
Glass Die Steel | Forging | ≤Φ400 |
Tool steel
«Mandril
Special mandrel steel: ZW33
Universal mandrel steel: H13
«Roller
Special roll steel: MC3, MC5, Cr12MoVCo, CC2
Universal roll steel: 9Cr2Mo
«High-speed tool steel
Special high speed tool steels, M42, M35
General-purpose high-speed tool steel: M2, 1.3343, 1.3344, W9Mo3Cr4V, M2Al……
Alloy tool steel
Special alloy tool steelA8MOD
Universal alloy tool steelCrWMn, 9SiCr, 6CrW2Si……
Carbon tool steel
Universal carbon tool steelT8, T10……
Tool steel main specifications
TYPE | CLASS | SIZE |
Mandril | Forging | Piece weight≤6t |
Roller | Forging | ≤Φ800 |
High-speed tool steel | Forging | ≤Φ240 |
Rolled Metal | ≤Φ90 | |
Alloy tool steel | Forging | ≤Φ800 |
Rolled Metal | ≤Φ150 | |
Carbon tool steel | Forging | ≤Φ300 |
Rolled Metal | ≤Φ150 |
