Quick Details

Si0 75Mn0 65Fe20 5Cr28Co50C0 08Main FeaturesUMCo50 is a heat-resistant cobalt alloy that has excellent thermal shock r

Delivery

  • Delivery status: Forged 、
  • Surface: Bright 、Milling 、
  • Standard: SAE
  • Shape: Round, Flat, Square, Hexagon, Plate, Sheet, Other

Inventory Status

Order

UMCo-50 Range of products
Product type Products Dimension Processes
Plates / Sheets Plates / Sheets 0.08-200mm(T)*W*L Forging, hot rolling and cold rolling
Steel Bar Round Bar, Flat Bar, Square Bar Φ8-1200mm*L Forging, hot rolling and cold rolling, Cast
Coil / Strip Steel Coil /Steel Strip 0.03-16.0x1200mm Cold-Rolled & Hot-Rolled
Pipes / Tubes Seamless Pipes/Tubes, Welded Pipes/Tubes OD:6-219mm x WT:0.5-20.0mm Hot extrusion, Cold Drawn, Welded

Related Grade

Product Details

Si 0.75
Mn 0.65
Fe 20.5
Cr 28
Co 50
C 0.08

Main Features

UMCo50 is a heat-resistant cobalt alloy that has excellent thermal shock resistance and wear resistance. It also shows great strength against sulfur-and vanadium-attacks. Another feature is its higher melting point compared to other cobalt base or nickel base heat-resistant alloys. For example, the alloy used for skid rails at a steel mill undergoes regular use at 1,350°C. Thus UMCo50 shows successful results in the application related to heat treatments and furnaces where other alloys could not be used due to their low melting point.

Shock Resistances

Since thermal shock resistance was given first priority when developing UMCo-50, this alloy shows far more outstanding thermal shock resistance than the popularly used 25Cr-20Ni stainless steel. For example, even after repeating the heating and cooling cycle (1000-water cooling-7 seconds) for 500 times, no cracking occurred. As a practical example, the alloy was used for four and a half years as a tray which was heated up to 1000 in a heavy oil furnace to quench various quenching agents. Hardly any cracking occurred in UMCo-50, whereas the 25Cr-12Ni alloys were able to be used for only 8 months in average.

Wear Resistances

As for the wear resistance of UMCo-50, hardly any deterioration was found after being used as a sintering bar for copper sulfide for 50 months. On the other hand, cast iron parts used till then were heavily corroded, oxidized and worn even though operations were conducted at 900, making them usable for only three and a half months.

Weldability

UMCo-50 can be welded together by arc or oxy-acetylene methods. When higher wear resistance is required, weld additionally with BISHILITE (HARDFACING ALLOYS). When welding UMCo-50 to stainless steel or steel, MA-W welding rod can be used.

Available Product Forms

Various shapes, such as flat-rolled plates, forgings, welding wires, wires, welded pipes and tubes, seamless pipes and tubes can be manufactured.

Technical Data

Physical properties, Mechanical properties, High temperature hardness, Example of stress-breaking strength, High temperature corrosion data are as shown below.

Physical Properties

Specific gravity Melting temperature Electrical Resistivity (25°C) Thermal expansion
(0∼1000°C)
Specific thermal conductivity
(22°C)
8.05 1380∼1395°C 82.5Ω•cm 16.8 X 10-6 /°C 0.022cal/cm/sec./°C

Mechanical Properties

  Tensile strength kgf/mm2 Yield strength(0.2%)kgf/mm2 Elongation%
3mm Sheet (Flat rolled) 90∼118 37∼46 10∼28
3mm Sheet : 1100°C X 30'Annealed 80∼90 30∼37 10∼20

High temperature hardness (Forgings)

Temperature (°C) Forgings (HV)
20 260
600 228
700 210
800 160
860 76
After work hardening 425

An example of stress-breaking strength

Temperature(°C) Stress kgf/mm2 Breaking time (hr) Elongation %
700 18 21.3 15.6
900 4 118.6 12.6

High temperature corrosion

  Temperature(°C) Time Reduced weight
g/m2 g/m2/hr
Plate (Flat rolled) 1000 144hr 26∼83 0.18∼0.58
Plate (Flat rolled) 1200 144hr 200∼120 0.69∼0.83

The results for 27Cr stainless at 1200°Cin 96hours are 300g/m2, 3.1g/m2/hr.
